AlpS 271 SaMASZ Saphir snow plow for wheel loaders up to 15t

Single blade AlpS snow plow with spring flaps and bar from Saphir SaMASZ

SaMASZ SNOW PLOWS:

From the super-light to the super-heavy series: SaMASZ snow plows are used in a variety of ways on city and country roads, sidewalks and parking lots. A comprehensive range of adapters and add-on frameworks enables use on almost any carrier vehicle.

Due to the wide range of possible uses, the robust design and the many possible special equipment, SaMASZ snow plows are ideal devices for clearing snow in winter service.

Weight class: Heavy class ~ wheel loaders up to approx. 15 tons

PSV basic equipment : Independently controlled shares • Infinitely variable hydraulic tilting + STANDARD control panel • Spring flaps • Hydr. Overload protection from model 361 • Scraper ( optional ) • Leveling (only with SaMASZ frame) • Safety chains • Electrical connection 12 V (cigarette lighter) •
LED lighting 12 V or 24 V • Parking support • Edge deflector • KTL layer + powder coating

Technical specifications:

working width max./min. [cm]: 270 / 245
Transport width max./min. [cm]: 284 / 257
Share height [cm]: 99 / 109
Scraper parts : 2 x 2 or 2 x 3 (please specify when ordering)
Collision protection: Automatic ratchet + shear bolts as overload protection in the attachment frame
Attack angle: 30°
hydraulic tilting: up to 30°
required number of hydraulic connections: 1 x DW
Dimensions [cm] length / width / height: 129 / 270 / 118
Weight [kg]: 665
